RVIT 15-60/15-120i – Rotary Variable Inductance Transducers
PERFORMANCE SPECIFICATIONS
ELECTRICAL SPECIFICATIONS
Parameter
Angular range
Input voltage
Input current
Sensitivity (*)
Output at range ends (*)
Output current
Output impedance
RVIT 15-60
±60 degrees
4.0 to 5.5VDC
14mA
10 mV/V/degree
±3.0VDC
2mA
1 ? maximum
RVIT 15-120i
0 to 120 degrees
10 to 28VDC (not to exceed 30VDC)
41mA
0.133 mA/degree
1 to 5VDC (with 250 Ohm loop resistor)
4 to 20mA
250? maximum
Temp coefficient of output
Non-linearity
Repeatability & hysteresis
Frequency response
Temperature range
Mechanical angular range
Bearings
Shaft diameter
Housing material
Mounting
Maximum torque
Shaft load capability
Electrical connection
Weight
±0.02% of FSO per oF [0.036% of FSO per oC], over operating temperature range
±0.25% of FR
0.1% of FRO maximum
25Hz @ -3dB
ENVIRONMENTAL AND MECHANICAL SPECIFICATIONS
0°F to +170°F [-18°C to 77°C] Operating; -67°F to +257°F [-55°C to 125°C] Storage
360 degrees (no stops)
ABEC 3 precision, matched and preloaded
3/16 inch [4.76mm]
Aluminum, black anodize
Size 15 servo mount BU-ORD (standard) or Flange mount with shaft seal (with accessory)
0.12 inch.ounce-force [8.6 gram-force.cm]
10 lb [4.5Kg] Axial and Radial
3 conductor cable, AWG 26, under PVC jacket, 12 inches [30cm] long
2.5 oz [70grams]
Notes :
All values are nominal unless otherwise noted
FR (Full Range) is the angular range, end to end; 2xAo for ±Ao angular range, Ao for a 0 to Ao range
FSO (Full Scale Output): Largest absolute value of the outputs measured at the ends of the range
FRO (Full Range Output): Algebraic difference in outputs measured at the ends of the range
(*) Ratiometric to input voltage
RVIT-15-60/15-120i Rev. 5
www.meas-spec.com
2/4
2014-January
